DESCRIPTION

Basic Info

Model NO.	Brass Ball Valve
Media	Gas
Material	Brass
Connection Form	Thread
Driving Mode	Manual
Nominal Pressure	1.6MPa-2, 5MPa
Channel	Straight Through Type
Structure	Fixed Ball Valve
Type	Fixed Ball Valve
Function	Bypass-Valve
Temperature	Normal Temperature
Standard	Standard or Nonstandard...
Application	Industrial Usage, Water Industrial Usage, Household Usage
Surface Treatment	Brass, Nickel-Plated, Chrome-Plated
Raw Material	Hpb57-3, Hpb59-1, Cw617n, Lead Free, Bronze
Thread	ISO228 G, NPT, Bsp
Port Size	Reduce Port, Full Port
Ball Material	Ss Ball, Brass Ball, Iron Ball
Stem Material	Brass Stem, Iron Stem
Handle Details	Chrome-Plated, Zinc Plated, Black Handle
Transport Package	Pallet and Carton
Specification	1/4 inch-4 inch
Trademark	ZTN
Origin	China
HS Code	8481804090
Production Capacity	300000sets/Month

Product Description

Basic Dates
1.Brass Material Used
HPB57%-3	CW614N	CuZn39Pb3	Lead Free Copper	C3604
HPB59%-1	CW617N	CuZn40Pb2
2.BasicTechnical Dates
Type Of Thread	Surface Treatment	Temperature	Pressure	Medium	100%
					Leakage
ISO228/BSP/NPT/JIS	Original Color Nickel Plated	0≤T≤ 120ºC	1.6MPA/2.5MPA	Water/oil/gas	Testing
	Chrome plated acid pickling

3.Description Of Parts
Ball	Stem	Sealing	Handle	Nut
Brass Ball With	Brass/Iron	PTFE	Iron Handle	Brass/Steel/Iron
Chrome Plated			Aluminum Handle
Iron Ball With			Butterfly Handle
Chrome Plated
chrome-plated ss ball

FAQ;
1. Can I have a sample order for valve? A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable. 2. Do you have any MOQ limit for valve order? A: Low MOQ, 1pc for sample checking is available. 3. How do you ship the goods and how long does it take to arrive? A: We usually ship by sea. It usually takes 30 days to arrive. Airline shipping also optional. 4. How to proceed an order for valve? A: Firstly let us know your requirements or application. Secondly We quote according to your requirements or our suggestions. Thirdly customer confirms the samples and places deposit for formal order. Fourthly We arrange the production. 5. Do you offer guarantee for the products? A: Yes, we offer 10 years warranty to our products.
